UGears Aero Clock Troubleshooting Video. How To? and other questions answered.
If you are having trouble setting the UGears Aero Clock, check out this useful video. Transcript is on this page below the video.
Download PDF Instructions
0:04 | If the pendulum is not operational
- Disconnect the latch to the right of the minute disc and slide the unit next to the latch toward you.
- Remove the additional part in the pendulum mount and disconnect the metal axle.
- Disconnect the pendulum.
- Wait for the mechanism to restart.
- Return the pendulum by securing it with the metal axle.
! If the pendulum does not move, sand the tips of the pendulum with sandpaper and rotate the disc by hand to grind in the pendulum.
- After restarting the clock, rotate the minute disc manually to 00 minutes.
- Connect the unit and secure the latch.
- Rotate the minute disc and check if the balloon is making a complete working cycle (smoothly lowering and raising).
01:37 | If the clock is lopsided
Apply the level tool to the wall (you can use a level or download the application on your phone) and rotate the eccentric of the clock to set the correct level of the clock holder.
01:46 | If the line got tangled or broken
- If the line that is in the shaft is tangled, remove part 153 and go through the assembly steps on pages 60 and 61 again.
- Also, make sure the line is properly secured to the upper rollers.
02:00 | If the balloon is incorrectly adjusted
- Rotate the minute disc for one revolution and make sure the balloon descends smoothly.
- To adjust the speed of the balloon, adjust the counterweight by adding or removing multiple weights.
! If the counterweight is too light, the balloon will drop sharply and can pull the line with it. If the counterweight is too heavy, the balloon will not be able to lower and the clock will not operate correctly.
02:43 | If the clock has stopped or the time is incorrect
- To wind the clock, pull the carriage-shaped weight as far as possible with one hand while holding the bag with a weight with the other hand.
- Check with a stopwatch that the escape wheel makes one revolution per exactly one minute.
- If the clock is slow, pull down the upper weight of the pendulum.
- If the clock is fast, pull up the upper weight of the pendulum.
- You can also use the lower weight of the pendulum to adjust the stroke of the pendulum.
If you did not find the answer to your question, or looking for a replacement part, please contact us at info@ugears.us
Shop for UGears Aero Clock Now
UGears Aero Clock - Frequently Asked Questions about Assembly
UGears Aero Clock - Frequently Asked Questions about Assembly
Related Posts
New UGears Star Wars™ Collection Has Landed!
Explore the Wonders of Space with UGears NASA Models 🚀✨
New Collection of UGears Mini Models
2023 Licensing International Excellence Awards Finalist - UGears Harry Potter™ collection!
Ugears awarded "Best Product of the Year" from Warner Bros. for its Harry Potter™ collection of mechanical models
Presenting 2.5D Mechanical Puzzles
Presenting Marble Run Tiered Hoist!
3 Comments
The balloon will rise until it is released by the missing cogs in part no 63, page 21, but just before this stage the counterweight has over-wound above top dead centre on part nos 128/130/131, page 49 and the clock is straining to overcome this addition weight, and stops. I have overcome this issue by removing the last cog on part 63, so the balloon drops as the counterbalance gets to top dead centre. May I suggest your diagram on page 21 showing the position of the gap in the cogs in relation to the minute indicator, part 66, be more explicit AND part 63 in the future has 3 cogs removed , rather than the two as existing? This type of stopping appears to be an issue with other modellers.
The Clock keeps perfect time and now runs for 12 hours – brilliant – thank you.
I cannot get my clock to wind. I have gotten it to wind up a couple of times, but something keeps stopping it from winding. Any thoughts?
Hi there,
I purchased and built an aero clock. Lots of fun to build, but now it only runs for 2 to 20 minutes and then stops. What do I need to do to fix it so that it runs correctly? Thanks much.
Joe
